500x580x820mm Undercounter ice cube machine for Commercial Use with
Plastic and SS Shell
Product feature of Commercial Ice Maker
We use world famous configuration ,the combination of stainless
steel and ABS plastic for appearance is elegant and easy to clean
and wash. The ice have a high hardness,the freezing point gets minus 20°C
below,crystal and clear,not easy to melt and cooling quickly. Ice
making is controlled by microcomputer,fully automated
watering,drainage,ice-making and off ice,without hand
operation,more safe and the performance is more reliable.
Saving spaces and placing conveniently; The feet can be adjusted, so we can adjust the height at will; Mute setting, there is no noise pollution; It's energy-efficient, low practical cost; We use food grade material, so our products are
environmentally-friendly and healthy.
Parameter of Commercial Ice Maker
| Product Description | Commercial Ice Maker |
| Model | ZH-105Y |
| Dimension(L*W*H)mm | 500*580*820with feet |
| Output(lb/24hr) | 110lbs=50kgs/24h |
| Bin Capacity (lb) | 44lbs=20kgs |
| Voltage (V/Hz) | 220V/50Hz |
| Compressor | Secop |
| Power (W) | 340 |
| Condenser Unit | Water Cooling |
| Refrigerant | R404A |
| Power Plug | 10A |
► Leading technology in the copper - nickel evaporation tray,
making ice fast, ice falling rapidly,saving time and saving
electricity;
► Reasonable increase of evaporation area, both to ensure full
yield, and improve the quality of ice;
► Microcomputer detection system, no need for special operation,
safe and reliable use;
► The scientific configuration of the condensing system and the
condensing temperature sensing device can adapt to different
ambient temperatures;
► The storage ice bucket adopts PE integral rolling plastic
process, which fully conforms to the national food gr ade access
standard, and the thickened foaming layer is for excellent ice
storage;
► Selecting the world famous parts, long service life, high
efficiency and energy saving;
► Hexahedral ice, with large contact surface, allows rapid cooling
of ice products;
► Stainless steel shell is luxury generous, easy to clean, and
durable.
Application of Commercial Ice Maker
Cube ice machines are suitable for: high-grade cafe, high-grade
bar, private club, starred restaurant, hotel, milk tea shop,
high-grade entertainment venue,etc.
Inner Components And Country of Origin
1. Compressor—Germany SECOP, USA Copeland;
2. Expansion Valve—Denmark Danfoss;
3. Defrost Solenoid Valve—Japan Saginomiya;
4. Condenser Fan—Germany EBM.
Operational Environment:
► Ambient temperature:2-43℃,water temperature:2-38℃,water
pressure:0.13Mpa~0.55Mpa
Space Requirement for Installation:
►The top and two sides of the machine should be at least 25cm away
from the wall, at least 12cm for the back of machine.
►The air outlet of air cooled machine should be free of
obstruction.
The maximum Daily Output is tested under:
►Room temperature of 20℃,Water temperature of 10℃.
Afer-sale Service
►We respect your feedback after you received the goods;
►We provide 12 months warranty for the whole unit;
►We promise all spare parts will be available during the lifetime
of the goods;
►We will respond to your complaint within 24 hours.
FAQ:
Q:1. What is the Payment Terms?
A:T/T: 30% in advance as deposit, 70% balance should be paid before
shipment.
Q:2. What is the delivery time?
A:Sample machines delivery during 7-15 days; orders delivery during
15-30 days.
Q:3. Can we put our own logo on the machine?
A:Yes, we can do OEM for you. ODM also is welcomed
Q:4. What is the warranty?
A:One year for the whole unit.
Q:5. Is sample order available?
A:Yes, it is. Sample order is acceptable.
