Water Cooled 118kgs Daily Output Ice Machine for Restaurant with
Brown Plastic Shell
Parameter of Electric Ice Machine
| Item | ZH-260Y |
| Dimension(L*W*H)mm | 670*680*920 with feet |
| Output(lb/24hr) | 260lbs=118kgs/24hours |
| Bin Capacity (lb) | 77lbs=35kgs |
| Voltage | 220V/50Hz |
| Compressor | Secop |
| Power (W) | 580W |
| Condenser Unit | Water Cooling |
| Refrigerant | R404A |
| Power Plug | 10A |
Product Feature of Electric Ice Machine
Bevel door design easy for taking ice; Sealed ventilation wall
design to guarantee better heat exhaustion; Left board, right
board, and roof board with integrated foaming to guarantee better
coolness maintain; High reliable and durable efficient ratio.
Size(mm) : 670*680*920; Power : 580W; Cooling Way : Water Cooling;
Ice Storage : 35kgs;
Material : Stainless Steel 304; Ice size : 22x22x22mm; OEM :
Acceptable
Operational Environment:
► Ambient temperature:2-43℃,water temperature:2-38℃,water
pressure:0.13Mpa~0.55Mpa
Space Requirement for Installation:
► The top and two sides of the machine should be at least 25cm away
from the wall, at least 12cm for the back of machine.
► The air outlet of air cooled machine should be free of
obstruction.
The maximum Daily Output is tested under:
► Room temperature of 20℃,Water temperature of 10℃.
The thickness of ice can be adjustable and using convenient to meet
different customer requirement.
Inner Components And Country of Origin
1. Compressor—Germany SECOP, USA Copeland;
2. Expansion Valve—Denmark Danfoss;
3. Defrost Solenoid Valve—Japan Saginomiya;
4. Condenser Fan—Germany EBM.
► Leading technology in the copper - nickel evaporation tray,
making ice fast, ice falling rapidly,saving time and saving
electricity;
► Reasonable increase of evaporation area, both to ensure full
yield, and improve the quality of ice;
► Microcomputer detection system, no need for special operation,
safe and reliable use;
► The scientific configuration of the condensing system and the
condensing temperature sensing device can adapt to different
ambient temperatures;
► The storage ice bucket adopts PE integral rolling plastic
process, which fully conforms to the national food grade access
standard, and the thickened foaming layer is for excellent ice
storage;
► Selecting the world famous parts, long service life, high
efficiency and energy saving;
► Hexahedral ice, with large contact surface, allows rapid cooling
of ice products;
► Stainless steel shell is luxury generous, easy to clean, and
durable.
Application of Electric Ice Machine
Cube ice machines are suitable for: high-grade cafe, high-grade
bar, private club, starred restaurant, hotel, milk tea shop,
high-grade entertainment venue,etc.
Warehouse
►We have enough space for raw materials, semi-finished products and
finished products;
►We will arrange the products of each customer and deliver them on
time;
►We will scientifically arrange the stock of conventional
ice-making machines to ensure the delivery of conventional products
within 72 hours.
Exhibition
Besides our Chinese domestic market, we are trying to develop other
markets around the world. Our products are widely used in
high-grade cafe,high-grade bar, private club, starred restaurant,
hotel, milk tea shop, hight-grade entertainment venue, ect.Our
service covers product analysis, project consultation,
manufacturing follow-up, exporting and after sales services.
Afer-sale Service
►We respect your feedback after you received the goods;
►We provide 12 months warranty for the whole unit;
►We promise all spare parts will be available during the lifetime
of the goods;
►We will respond to your complaint within 24 hours.
FAQ:
Q:1. What is the Payment Terms?
A:T/T: 30% in advance as deposit, 70% balance should be paid before
shipment.
Q:2. What is the delivery time?
A:Sample machines delivery during 7-15 days; orders delivery during
15-30 days
Q:3. Can we put our own logo on the machine?
A:Yes, we can do OEM for you. ODM also is welcomed
Q:4. What is the warranty?
A:One year for the whole unit, three years for the compressor.
Q:5. Is sample order available?
A:Yes, it is. Sample order is acceptable.
